- Heavier design build, allowing for over the road transport… and, 10% lighter.
- No priming necessary to start!
- NEW steel pontoons:
- Design built for even better durability and maneuverability for exit and entry of manure lagoons.
- Allows for easier movement of back nozzels.
- Provides durability in icy conditions.
- Remote control joysticks designed to keep fingers on joysticks and eyes on the boat
- Up/down hydraulic wings.
- Up/down hydraulic hitch.
- Up/down hydraulic rear wheels.
- Hydraulic knife valve to shut off front nozzle when coming to shore.
- GEA Farm Technologies 8” super pump.
- Proven John Deere power unit.
- 5 LED lights for nighttime use.
JT Boat joystick control box is easy to operate. Operator can keep their eyes on the manure agitator, not the control box. With each nozzle having its own joystick, the boat can maneuver forward/backward, side-to-side, or circular motion at any time.
|Width||Wings up: 8.5 ft. Wings down: 15 ft.|
|Engine||John Deere 6.8 Ltr. 275 hp.
Fuel capacity: 115 gallons
|Centrifugal Pump||GEA 8″ super pump
No priming necessary
|Remote Control Functions||Engine start/stop
Engine throttle increase/decrease
Rear Wheels raise/lower
|Agitation/ Nozzles||3 Rotating nozzles allow for forward/backward, side-to-side, or circular motion at any time.
Above ground nozzles allow user to spray down banks in lagoons.
Gate valve to shut front nozzles off when coming to shore.
|Hydraulic Hitch||Safely hook/unhook from tractor when backing up or retrieving boat from manure lagoon.
Breaking ice in icy conditions.
|Hydraulic Wheels||Hydraulic wheels may go down to assist in getting in and out of manure lagoon.
“Depth finder” Hydraulic wheels may be used to find banked solids in manure lagoons.
Hydraulic wheels may go down five feet to assist getting around manure lagoons
Hydraulic wheels may be used as an “anchor” in the manure lagoon for washing down banks or docking boat for nighttime hour.
1700 Series JT Boat bringing up solids from bottom of pit1700 Series JT Boat's ability to point nozzles straight down allows the user to stay in one spot while penetrating the solids at bottom of lagoon. Notice the solids surfacing.
1700 Series JT Boat working in a pitHere we have a JT Boat mixing up a corner of a plastic lined lagoon. Notice the volume of material being moved and the solids that it is breaking apart below the surface.
1700 Series JT Boat transferring solids across pit to load out pumpJT Boat's ability of efficiently mix solids on opposite side of pit and simultaneously position front nozzle to transfer solids towards load out pump. All this while continuing to keep your eyes on the boat and hands on the joystick controls.
1700 Series JT Boat entering a manure lagoonLaunching a 1700 Series JT Boat into pit with a plastic liner. Front hitch wheel kit is add-on feature.
Pulling a JT Boat 1700 Series out of a lagoonPulling a JT Boat 1700 Series out of a lagoon
JT Boat 1700 Series. Manure Agitation done right!
JT Boat 1700 Series Boat in Actionmanureagitators.com
JT Boat (1500 Series) Manure Agitator - Full Overview
JT Boats - Agitation done right!
JT Boats - Hooking and Unhooking
JTBoats - Demolishing a Sandbar
Problematic Conditions? No Problem! The JT Boat manure agitator has a clear cut advantage in these adverse conditions and more…
Thick Crust Conditions:
Simply direct nozzles above crust, soaking and breaking the stubborn crust up as it sinks and mixes into the slurry.
The JT Boat easily is able to move sand through pump and throw it out front nozzle, moving the sand pile across pit (to pump feeding drag lines or tanks).
Extreme force of liquids coming out nozzles breaks up ice, while the steel floats are able to withstand the wear and tear of floating ice chunks.
Extreme Sand Conditions:
The JT Boat quickly and efficiently gets to work, providing a slurry consistency that is similar to the first hour on the job, to the last.
